1. You need have a simulation SW. Such as Candance or Mentor,although you can use Xinlix or Altera tools, those SW only can simulate digital signal
2. Build a test bench by verlog or VHDL(I use VHDL), the interface with you circuit must define clearly.
3. Compile you hardware circuit,include in the tools.
4. After you debug some error, you can see the signal...
This is only the procedure, you can reference Mentor or Candance SW tools introduction. Before you study this, the English is the basic.
请看上图。 三端稳压集成电路也称三端稳压管，它的样子就像是普通的三极管，电子产品中常见到的三端稳压集成电路有正电压输出的78×× 系列和负电压输出的79×× 系列。顾名思义，三端IC是指这种稳压用的集成电路只有三条引脚输出，分别是输入端、...
