UL是美国保险商实验室（Underwriter Laboratories Inc.）的简写。UL安全试验所是美国最有权威的，也是世界上从事安全试验和鉴定的较大的民间机构。它是一个独立的、非营利的、为公共安全做试验的专业机构。它采用科学的测试方法来研究确定各种材料、装置、产品、设备、建筑等对生命、财产有无危害和危害的程度；确定、编写、发行相应的标准和有助于减少及防止造成生命财产受到损失的资料，同时开展实情调研业务。
758规格页上面已经写的很清楚了。
铜线规格，绝缘厚度，耐温温度和耐压参数等等，都已经有具体数字说明了。
不知楼主所问的-------都是什么样的导线----具体的规格----这个到底要问什么？
具体区别在规格页里面都可以做比较了。
按照UL758标准来做的电线，各企业的产品多少还是有些差别的（比如说线径，铜丝规格），但只要条件满足标准规定的内容，就都是可以的。
===================================================================
UNDERWRITERS LABORATORIES INC. APPLIANCE WIRING MATERIAL
Subj. 758 Section 1 Page 1007 Issued: 1959-05-01
Revised: 2002-12-05
Style 1007 Polyvinyl Chloride Insulated Wire.
______________________________________________________________________________
Rating 80?C, 300 V.
______________________________________________________________________________
Conductor 32-16 AWG, solid or stranded.
______________________________________________________________________________
Insulation Polyvinyl Chloride, 15 mils minimum average,
13 mils minimum at any point, 60 or 80?C in oil,
if applicable.
______________________________________________________________________________
Standard Appliance Wiring Material UL 758.
______________________________________________________________________________
Instructions Detailed Examination.
to UL Physical Properties, Unaged.
Representative Spark Test.
______________________________________________________________________________
UL (4) Detailed Examination.
Counter-Check (4) Physical Properties.
Program (4) Heat Shock.
(4) Cold Bend
* (4) Deformation.
* (12) Horizontal Flame Test.
______________________________________________________________________________
Marking General.
______________________________________________________________________________
Use Internal wiring of appliances; or where exposed to oil
at a tempera?ture not exceeding 60°C or 80°C, whichever
is applicable. Tags may indicate the following:
600 V Peak - For Electronic Use Only.
==================================================================
UNDERWRITERS LABORATORIES INC. APPLIANCE WIRING MATERIAL
Subj. 758 Section 1 Page 1347 Issued: 1963-10-16
Revised: 2003-03-31
*Style 1347 PVC Insulation with PVC Jacket.
______________________________________________________________________________
Rating 80?C, 300 V.
______________________________________________________________________________
Conductor No. 26-16 AWG, stranded or solid, tinned or bare copper.
______________________________________________________________________________
Insulation 16 mils minimum average, 13 mils minimum at any point, wall
of thermoplastic (PVC) rated 80?C.
______________________________________________________________________________
Shielding Conductive thermoplastic, aluminum-faced "Mylar", copper
braid or wrap, or equivalent; optional uninsulated drain
wire.
______________________________________________________________________________
Jacket Over the shielding, 16 mils minimum average, 13 mils
minimum at any point, thermoplastic (PVC) shall be applied,
rated 80?C.
______________________________________________________________________________
Standard Appliance Wiring Material UL 758.
______________________________________________________________________________
Instructions Detailed Examination.
*to UL Tensile Strength and Elongation of Insulation and Jacket.
*Representative Spark Test.
______________________________________________________________________________
UL (4) Detailed Examination.
Counter-Check (4) Tensile Strength and Elongation of Insulation
Program and Jacket.
(4) Heat Shock.
(4) Cold Bend.
(4) Deformation.
* (12) Horizontal Flame Test.
______________________________________________________________________________
Marking General.
______________________________________________________________________________
Use In electronic equipment where exposed to temperatures
not exceeding 80?C.
==================================================================
UNDERWRITERS LABORATORIES INC. APPLIANCE WIRING MATERIAL
Subj. 758 Section 1 Page 1185 Issued: 1959-05-01
Revised: 2003-03-31
Style 1185 PVC Insulated, Shielded and Jacketed Wire.
______________________________________________________________________________
Rating 80?C, 300 Volts.
______________________________________________________________________________
Conductor Copper - 30-4/0 AWG, solid or stranded, tinned or bare.
______________________________________________________________________________
Insulation Extruded PVC, Class 43
AWG Min. Avg., Mils Min. at any point Mils
30-16 15 13
15-10 30 27
9-8 45 40
7-2 60 54
1-4/0 80 72
______________________________________________________________________________
Shield Optional.
______________________________________________________________________________
Jacket Extruded PVC, Class 43
AWG Min. Avg., Mils Min. at any point Mils
30-16 15 12
15-2 30 24
1-4/0 45 36
30-16 or lacquered braid
______________________________________________________________________________
Shield Optional.
______________________________________________________________________________
Jacket Optional. PVC, Class 43, 15 mils minimum average,
12 mils minimum at any point.
______________________________________________________________________________
Standard Appliance Wiring Material UL 758.
______________________________________________________________________________
Instructions Detailed Examination.
to UL Physical Properties of Insulation and Jacket.
Representative Spark Test.
______________________________________________________________________________
UL (4) Detailed Examination.
Counter-Check (4) Physical Properties of Insulation and Jacket.
Program (4) Heat Shock.
(4) Cold Bend.
(4) Deformation.
* (12) Horizontal Flame Test.
______________________________________________________________________________
Marking General.
______________________________________________________________________________
Use Internal Wiring of Appliances and Electronic Equipment.
====================================================================
