ZL50E轮式装载机基本参数
ZL50E WHEEL LOADER SPECIFICATIONS
发动机型号…………………………………………………………..WD615.67G3-36
D6114ZGB
Engine Model
功率（kW/PS）……………………………………………………………162/160
Power
额定转速（r/min）…………………………………………………………..2200
Rated Revolution
额定载重量（t）………………………………………………………………5
Rated Load Weight
最大卸载高度（mm）（斗尖/斗刃）………………………………………2990/3104
Max. Dump Clearance （Up to Tip/Up to Edge）
最大卸载距离（mm）（斗尖）……………………………………………………1220
Max. Dump Reach （Up to Tip）
最高行驶车速（km/h）……………………………………………………………36
Max. Travel Speed
最小转弯半径(mm)………………………………………………………………6520
Min. Turning Radius
最大牵引力（KN）………………………………………………………………..165
Max. Traction Force
工作装置动作时间（三项和）（s）……………………………………………12.5
Hydraulic cycle time (Total)
额定斗容（m3）………………………………………………………………….3
Rated Bucket Capacity
掘起力（kN）…………………………………………………………………..180
Breakout Force
总长度（mm）………………………………………………………………….8250
Overall Length
总宽度（mm）………………………………………………………………3000
Overall Width
总高度（mm）………………………………………………………………3520
Overall Height
操作重量（t）………………………………………………………………. 16.2
Operating Weight
特点
Features:
发动机
本机采用斯太尔WD615.67G3-36发动机，或可选配上柴D6114，动力强劲
Optional Engine Steyr diesel engine WD615.67G3-36, and Shanghai diesel engine D6114.
变速系 吸收了卡特技术的双涡轮液力变矩器，动力换档变速箱，结构紧凑，高效、可靠，操纵方便；主要轴承采用进口件；
Power Train Twin turbine torque converter, manufactured by Cheng Gong and employing CAT technology, and power shift transmission which features compact structure, high efficiency, reliable performance, and operational ease. The key bearings are imported.
驱动桥 采用技术成熟的、性能优良的成工50桥，承载能力大，可靠性高；关键密封件采用进口产品；
Axles Heavy duty and reliable axles designed with advanced Cheng Gong Series 50 axle technology. Key seals are imported.
液压系统 全液压转向系统，操纵轻便灵活，性能可靠。流体连接件采用国内知名品牌，密封可靠，管路系统寿命高；采用PERMCO的泵；
Hydraulic System Full hydraulic steering system with operational ease and high efficiency. Well known hydraulic fluid connections with reliable seals ensure long service life of line system. PERMCO pumps used.
工作装置 工作装置优化设计的Z型连杆机构，掘起力大，作业效率高，循环时间短；斗容大，卸载高度、卸载距离大，适合更大范围的需求；其销轴采用防尘结构设计，延长了使用寿命，缩短了维修周期。
Implement Optimally designed Z-bar linkage mechanism with large breakout force, high efficiency, short cycle time, large dump clearance and reach, and suitable for a wide variety of applications. Dust proof pins ensure its long service life.
驾驶室 符合人机工程的驾驶室，密闭、隔热、减震，降噪，操纵舒适，视野广阔；
Cab Ergonomically designed for total control and comfort with impressive panoramic visibility. It features heat insulation, shock absorption, and low noise level.
车架 四板塔型前车架与箱型后车架为主机提供了坚实的受力基础，上下铰接间距大，采用圆锥滚子轴承，寿命长；整机稳定性好；
frame Heavy-duty front frame with four-plate loader tower and rear frame with special box-section structure provides strength and large load capacity. It features long upper and lower hitch distance, cone bearing which ensure extended service life, and a long wheelbase design which results in improved centre of gravity and stability.
整机布置 整机布置合理，液压油箱上置，燃油箱后置，维修性好，弧性机罩使外观更为协调、美观，后视效果好；
Vehicle Arrangement Improved positioning of the hydraulic tank (higher position), and the fuel tank (rear of machine). Compact structure with easy access to service points ensures hassle-free maintenance. Attractive and improved cabin and overall machine design with streamlined engine hood for superior rear visibility.
可选配件 空调、加大斗、石方斗、加长臂、破碎锤，以及集装箱叉、钢管叉、木柴叉、起吊臂等多种作业装置，满足您的各种需求；
Optional Equipment Air-conditioning
Large, light material buckets
Bucket for rock
Extended lift arms
Hydraulic hammer
Multi-purpose implements including log, container and steel tube forks, and hoisting arm.
破碎锤技术特点
Features of Hydraulic Hammer:
● 强劲的击打力量
●Strong crushing force
● 极高的系统效率
● High system efficiency
● 科学的构造、优良的材质、先进的工艺，保证了卓越的耐久性
● Scientific structure，good quality material，and advanced processing ensure the best durability.
● 简单的结构、极佳的油脂润滑位置、无氮气泄漏的后盖，使维修保养异常便利。
● Simple structure，ideal greasing position and rear cover with nitrogen gas leakage proof make the maintenance very easy.
成工产品破碎锤技术参数：
Specifications for Cheng Gong Hydraulic Hammer：
破碎锤重量 467-889 kg
Operating Weight
驱动压力 130-180 bar
Hydraulic pressure
驱动油量 45-140 lpm
Oil Flow
击打频率 400-820 bpm
Frequency
钢钎直径 85-105 mm
Tool Diameter
击打力 1200-2750 J
Crushing Force
ZL50E轮式装载机配破碎锤产品的整机参数：
Specifications for ZL50E Wheel Loader attached the hydraulic hammer：
整机重量 15500 ~ 16000kg
Operating Weight
长 8186mm
Length
宽 3000mm
Width
高 3520mm
Height
*内容及规格参数如有变更，恕不另行通知。
*Materials and specifications are subject to change without notice.
